Product Name: gyxtw outdoor single mode central bundle tube optical cable
Core: 4/6/8/12 core
Reinforcing wire: 1.4 mm
Sheath quality: HDPE black sheath
Core size: 4-12ala
Attenuation: 850 nm ≤ 3.5 dB/km 1300nm ≤ 1.5 dB/km
Allowable stretching force: long-term=600N, short-term=1500N
Allowable flattening force: long-term=300N, short-term=1000N
Bending radius static/dynamic: static less than 10 times the outer diameter of optical cable dynamic less than 20 times the outer diameter of optical cable
Outer diameter of optical cable: 8.0 mm x 0.2 mm
Cable weight: 58 kg/km
Laying method: overhead, pipeline
Storage/service temperature: - 40 degrees to+60 degrees
Service life: 20 years
