Cable Type：Category 5e

Shielding Type：F/UTP

Cable Jacket：PVC and LDPE

Cable Length：1000ft (305m)

Reference Bandwidth：350MHz

Data Rate Support：10/100/1000Base-T

Wire Gauge：24AWG

Conductor Type：Solid Pure Bare Copper

Standard：YD/T 1019-2023

Number of Conductors：4 Pairs

Putup Type：Reel

Conductor Diameter (mm)：0.500 ± 0.005

Cable Outer Diameter (mm)：7.4 ± 0.5

Maximum Installation Tension (N)：110

Bend Radius (mm)：31.6

Operating Temperature：-40 to 75°C (-40 to 167°F)

Installation Temperature：-20 to 60°C (-4 to 140°F)
